Product Specifications

● Size : 46in(L)x27in(W)x35in(H)
● Table size : 46in(L)x27in(W)
● Hight of the table : 17in(Min)?40(Max)
● Speed of lifter : 0.24in/s
● Weight: [PC020-04]?115kg
● Speed : High-speed/Low-speed switchable
〔High speed setting〕3.6mi/h (Forward) ? 1.2mi/h (Backward)
〔Low speed setting〕1.9mi/h (Forward) ? 0.8mi/h (Backward)
● Max.Load capacity : [PC020-04]?500kg
● Max.Climbing angle : Slope 12°?
● Carrier area : 36in(L)x20in(W)
● Carrier hight: 20in
● Motor : Wheel motor 350W / RPM:80/min
? ?(Overcurrent protection circuit)
● Brake system : Disc brake / Brake lever with stopper
● Frame : Low carbon steel
● Surface treatment: Powdered baking finish
● Front tire(2): 13x5.00-6 (Pneumatic tire)
● Rear tire(2): 3.00-4 Caster type (No flat tire)
● Min.Tuming radius : 27in
● Battery : DC24V,24A Electrolyte lead storage battery (Encapsulated type)
● Power switch key (3)
● Grip throttle speed adjustment (0 position automatic retractable)
● Forward/backward drive-shift switch Battery indicator
● Rapid charging function : (charging time : 8hours)
● Charger : (input) 100V～240V/50～60Hz (output) DC29V 3.5A
● Operating temperature range : 32°F～104°F
● NW : [PC020-03] 2201b ? [PC020-04] 2551b
● Qty per 20HQ/40HQ Container(pcs):90/180
● Made in China
